loader

  • Including two Li-ion 3S4P battery packs
  • DC 10.8V output; capacity: 12060mAh
  • Compatible with remote battery management solution
  • LED battery life indicator button
  • Light-weight and easy handling design
  • Medical grade certified

Specification

Battery Type

3S4P / 12 Cell Li-ion battery

Battery Voltage

10.8V

Battery Capacity

12060mAh

Warranty

1 year

Compatible

Venus all series,UPower all series

Safety

Supports protection from over-voltage (input and output), over-current (input and output), short circuit, over-charge, over-discharge and
battery Positive Temperature Coefficient (PTC)

Certifications

IEC-62133-1, UL, CE, IEC-60950-1

Architecture

ABS + PC

Color

White

Dimensions

150(L) x 80(W) x 45 (H) mm

Net Weight

430g

Packing Size

230(L) x 230(W) x 90(H) mm

Gross Weight

1.5kg (1.98 lbs)

Operating Temperature

0°C ~40°C( 32°F ~104°F)

Storage Temperature

-20°C ~ 60°C (-4°F ~ 140°F)

Storage Humidity

10%~95%@35°C, non-condensing

One LED Flashing

0%~5% capacity

One LED Lighting

5%~20% capacity

Two LED Lighting

20%~40% capacity

Three LED Lighting

40%~60% capacity

Four LED Lighting

60%~80% capacity

Five LED Lighting

80%~100% capacity
